Size 15.2 - 18.2 Combustion module - CAK and CBK conguration
The presence of optional accessories may result in a substantial variation of the weights shown in the table.
Size 15.2 18.2
Conguration CAK/CBK CAK/CBK
W1 supporting point kg 230 235
W2 Supporting point kg 274 281
W3 Supporting point kg 269 275
W4 Supporting point kg 257 261
Operating weight kg 1030 1052
Shipping weight kg 1030 1052
1. Compressor compartment
2. Electrical panel
3. Condensate drain
4. Functional clearances
5. Internal exchanger
6. External exchanger
7. H2O heating coil / Electric heaters (Optional)
8. Re-heating coil (Optional)
9. G4 air lters (Standard)
10. F7 bag lters / H10 electronic air lters (Optional)
11. Electric fan (Supply - return)
12. External electric fan
13. Outdoor air damper (CBK cong.)
14. Access for inspection of coils, lters, heating elements
15. Lifting brackets (removable)
16. Humidier connections
17. H2O heating coil input Ø 1”1/4
18. H2O heating coil output Ø 1”1/4
19. Gas module
(RO) Horizontal air return
(R3) FLoor air inlet (optional)
(M0) Horizontal air supply
(AE) Outdoor air return (only for CBK conguration)
(H1) Wall with same height as unit on a maximum of three sides
(**) Suggested clearance
(*) Vibration mounts position
