M08F40N15-02 CSRN-XHE2 15.2-44.4 33
10 Accessories
10.1 Congurations
CAK Conguration with single fan section for full recirculation
CBK Conguration with single fan section for recirculation and fresh air
CCK Conguration with double fan section for recirculation, fresh and exhaust air
CCKP Conguration with double fan section with fresh air and THOR thermodynamic recovery
1. G4 eciency lters + H10 equivalent electronic lters
2. Hot water exchanger or electric heaters
3. Handling exchanger
4. Hot gas reheating exchanger
5. Return + supply fan section
6. Source side exchanger
7. Electrical panel
8. Exhaust fan
9. Overpressure damper
10. Thermodynamic recovery exchanger, THOR
R Return air FA Fresh air
S Supply air EX Exhaust air
