CLIVET WSAN-XIN 21 - Technical Information and Specifications; Unit Dimensional Data

48
9 - TECHINICAL INFORMATION
378
412
166
942
992
1
1
1
1
2
2
3
4
5
6
7
912 1515
2033420
150
100
500
143372
65
67
A
DETTAGLIO A
60
8
9
9
9
895
(1) HOLES TO HANG ANTIVIBRATION MOUNTS
(2) LIFTING HOLES
(3) ELECTRICAL PANEL
(4) ELECTRICAL POWER INPUT
(5) CONTROL KEYBOARD
(6) INTERNAL EXCHANGER WATER INLET (1" GAS)
(7) INTERNAL EXCHANGER WATER OUTLET (1" GAS)
(8) CONDENSATE DISCHARGE
(9) CLEARANCE ACCESS RECOMMENDED
WW
W
W
SIZE 21 31 41
Length mm 895 895
Depth
mm 378 378
Height
mm 992 992
W1
kg 37 38
W2
kg 17 18
W3
kg 39 40
W4
kg 19 20
Operating weight
kg 112 116
Shipping weight
kg 110 114
895
378
992
40
20
42
22
124
122
9.1 DIMENSIONALI
