9 - TECHINICAL INFORMATION
9.1 DIMENSIONALI
20 365 20
15 1057 15
148
1087
440
1234
1
1
1
1
2
2
3
4
5
6
7
500
150
100
119568
70
73
410
A
DETTAGLIO A
60
8
9
9
9
1038
(1) HOLES TO HANG ANTIVIBRATION MOUNTS
(2) LIFTING HOLES
(3) ELECTRICAL PANEL
(4) ELECTRICAL POWER INPUT
(5) CONTROL KEYBOARD
(6) INTERNAL EXCHANGER WATER INLET (1" GAS)
(7) INTERNAL EXCHANGER WATER OUTLET (1" GAS)
(8) CONDENSATE DISCHARGE
(9) CLEARANCE ACCESS RECOMMENDED
WW
W
W
SIZE 51 71
Length mm 1038 1038
Depth
mm 410 410
Height
mm 1234 1234
W1
kg 51 53
W2
kg 32 33
W3
kg 53 55
W4
kg 34 34
Operating weight
kg 170 175
Shipping weight
kg 168 173
