CLIVET WSAT-XIN Series User Manual

PREMIUM VERSION
Sound levels
Size
Sound power level
Sound
pressure level
Sound power
level
Octave band (Hz)
63 125 250 500 1000 2000 4000 8000 dB(A) dB(A)
21 73 73 70 65 63 59 51 36 49 64
31 76 70 65 60 58 53 46 48 49 64
41 76 71 66 61 59 54 47 49 49 64
51 76 71 69 66 63 58 50 39 53 68
71 77 71 69 67 63 59 50 40 54 69
81 83 77 69 61 63 67 60 61 56 72
91 84 79 70 62 64 67 60 61 56 72
101 86 81 72 62 65 67 60 61 57 73
121 81 73 67 61 63 67 61 61 55 71
131 85 76 70 61 64 67 61 61 56 72
141 86 79 72 63 65 68
61 62 57 73
Sound levels refer to units with full load under nominal test conditions.
The sound pressure level refers to a distance of 1m from the outer surface of the unit operating in an open eld.
Noise levels are determined using the tensiometric method (UNI EN ISO 9614-2)
Data referred to the following conditions:
- internal exchanger water = 12/7 °C
- Ambient temperature = 35 °C
Sound levels
Size
Sound power level
Sound
pressure level
Sound
power level
Octave band (Hz)
63 125 250 500 1000 2000 4000 8000 dB(A) dB(A)
21 73 73 70 65 63 59 51 36 49 64
31 76 70 65 60 58 53 46 48 49 64
41 76 71 66 61 59 54 47 49 49 64
51 76 71 69 66 63 58 50 39 53 68
71 77 71 69 67 63 59 50 40 54 69
81 83 77 69 61 63 67 60 61 56 72
91 84 79 70 62 64 67 60 61 56 72
101 86 81 72 62 65 67 60 61 57 73
121 81 73 67 61 63 67 61 61 55 71
131 85 83 75 70 78 69 63 64 63 80
141 85 83 80 79 83 75 72 61 69 85
151 88 86 81 80 84 75 72 61 70 86
161 93 91 85 85 87 78 75 65 73 89
171 94 84 85 85 87 78 75 65 73 90
Sound levels refer to units with full load under nominal test conditions.
The sound pressure level refers to a distance of 1m from the outer surface of the unit operating in an open eld.
Noise levels are determined using the tensiometric method (UNI EN ISO 9614-2)
Data referred to the following conditions:
- internal exchanger water = 12/7 °C
- Ambient temperature = 35 °C
EXCELLENCE VERSION
Admissible water ow rates
Size 21 31 41 51 71 81 91 101 121 131 141 151 161 171
Minimum ow [l/s] 0,15 0,18 0,18 0,23 0,34 0,35 0,35 0,35 0,42 0,42 0,42 0,42 0,48 0,48
Maximum ow-
rate
[l/s] 0,90 0,90 0,90 1,10 1,50 1,95 1,95 1,95 2,70 2,70 2,70 2,70 2,70 2,70

