L-47
Elektr. und mech. Beschreibung / electr. and mech.
description / description méc. et électr. GLC 353/503/553 MC3
Pos. Bestell-Nr./Ref.-No./ Bezeichnung / Description / Désignation
Référence
Elektrische Stückliste - Schalt.-Nr. 2540 / Electrical parts list - diagram No. 2540 /
Liste des pièces électriques - schéma no. 2540
010 09 18 03 Crimpstift 0,75-1,0mm
2
25 Stück / crimp pin 0,75-1,0mm
2
, 25 off /
pin 0,75-1,0mm
2
, 25 pcs.
X5 604 04 06 00 Pistolen Z-Anschluß kpl. / torch central connection compl. /
raccord central de la torche, cpl.
X10 011 03 85 00 2pol. Buchsenleiste 3,96/2 pole multiple plug 3,96 / prise multiple à 2 pôles 3,96
X11 011 03 87 00 7pol. Buchsenleiste 3,96/7 pole multiple plug 3,96 / prise multiple à 7 pôles 3,96
X12 011 03 89 00 11pol. Buchsenleiste 3,96 / 11 pole multiple plug 3,96/
prise multiple à 11 pôles 3,96
X13 011 03 86 00 5pol. Buchsenleiste 3,96/5 pole multiple plug 3,96 / prise multiple à 5 pôles 3,96
X14 an M1 Gehäuse 2pol. für Flachstecker / 2 pole housing for flat plug /
embase à 2 pôles pour fiche plate
an M1 Flachstecker 6,3 2 Stück / flat plug 6,3, 2 off / fiche plate 6,3, 2 pcs.
X15 an M1 Flachstecker 6,3 2 Stück / flat plug 6,3, 2 off / fiche plate 6,3, 2 pcs.
X16 011 03 91 00 13pol. Buchsenleiste 3,96 /13 pole multiple plug 3,96 /
prise multiple à 13 pôles 3,96
Y1 032 02 05 00 Magnetventil für Schutzgas /solenoid valve for shielding gas /
vanne magnétique pour gaz protecteur
033 17 82 00 Fernreglersteckdose für CK 98 A, Einbausatz kpl. bestehend aus:
remote controller socket for CK 98 A, installation kit composed of:
prise commande à distance pour CK 98 A, kit d'installation se composant de:
X7 010 09 10 05 25pol. Anbaugehäuse mit Klappdeckel / 25 pole attached housing with hinged
cover / embase à 25 pôles avec couvercle à charnière
010 09 18 12 25pol. Buchsenteil / 25 pole bush / douille à 25 pôles
010 09 18 10 Crimpbuchse 0,75-1,0mm² / crimp bush 0,75-1,0mm² / douille 0,75-1,0mm²
X17 011 03 88 00 10pol. Buchsenleiste 3,96 / 10 pole multiple plug 3,96 /
prise multiple à 10 pôles 3,96
X18 011 03 90 00 12pol. Buchsenleiste 3,96 / 12 pole multiple plug 3,96 /
prise multiple à 12 pôles 3,96
