B-20
Welding
GLC 353/503/553 MC3
B2.5 Procedure: Coated stick electrodes
The power source provides the operating mode Electrode for welding coated stick
electrodes.
Please proceed as follows:
- Switch machine on
- Select the Operating mode by pressing the following key:
When welding with Electrode the lower LED flashes
(see photo).
During this welding process it is not required to set the values Operating Mode,
Material , Gas and Wire Diameter.
Caution!
Open circuit voltage is available at the connection lugs P and N and
at the stick electrode!
- Set Display 2 by pressing
the selector key until A
Set
appears for the current set
value.
After setting, the LEDs light up as
shown on the photo.
B2.5 Coated Stick Electrodes
