B-44
Options
GLC 353/503/553 MC3
Accessories coding forGLC 353/553 MC3, MC3/R
Set values Set values External Wire current- Robot CK change-over
of CK external start less from torch version external
8,2 k 1V x - x - - -
3,6 k 2V
2,2 k 3V
1,3 k 4V
910 5V - x x - - x
620 6V x - x - - x
390 *7V - x x x - -
220 8V
100 *9V x - x x - -
0 10V - x x x x x
* Version 1.50 and higher
Resistor or bridge in
GLC...MC3
Automation socket X15
between A1 (+10V) and B7 (accessories coding)
GLC...MC3/R
Peripheral socket X15
between 31 (+10V) and 28 (accessories coding)
