B-3
Operation
GLC 353/503 MC3
E Introduction
The GLC 353/503 MC3 MIG/MAG power source with CK 98 A wire drive unit is adjusted
with regard to the arc capacity. You select the material, the shielding gas and the arc
power to be used and the processor, which is integrated in the power source, provides an
optimized arc based on the selected values. Ajustment is possible via the wire feed speed
(or weld current) and arc length.
The power source enables programming of up to 50 welding processes (Jobs).
The first part of this operation manual informs you about the input elements and the
procedures required for welding.
The second part informs you how to program and call up the weld processes.
B Operation
B1 Operating and display elements
The operating and display elements are on the
front plate of the
wire drive unit
and the
power source
B1 Operating and display elements
