MAN.234 Rev.6 ENG - Use and maintenance manual S19HD page 80 of 126
6 Electrical system
The MEWP is electrically supplied when the key is
inserted and rotated in position 1 (Picture 4).
Periodically check the efficiency of the electrical
system: battery, alternator, regulator alternator
charge.
The electrical system is attached to this manual.
Any operation requiring interventions on the
components of the machine, shall carried out
by authorized and trained staff.
It is forbidden to replace the components for
non-authorized staff. Many components of
the MEWP have been calibrated: a correct
calibration of these parts (which is possi-
ble only in C.M.C. or in authorized Ser-
vices) is important to assure the safety of
the machine.
• FUSE BOX (Picture 84):
At view on machine switching on/off station,
there is a fuse box where it is possible to find all
the machine fuses. You can also identify the
burnt ones through the lighting of a related spy.
Picture 84: fuse box.
