MAN.234 Rev.6 ENG - Use and maintenance manual S19HD page 47 of 126
4.4.6 Setting the MEWP in transport
configuration
15. In order to position the MEWP in the
transport configuration, it is first necessary to
centre the turret, then obtain the return of the
telescopic boom and the pantograph on their
support, using the (operating) platform con-
trol station (par. 3.2.1).
WARNING! CENTER THE TURRET
BEFORE LOWERING BOOMS.
16. Unfasten the safety belts, get off from the
basket using the steps below.
Keeping the parking button P (Picture 8) pressed,
together the J5 joystick which control the turret rota-
tion, you can activate the turret self-centering up to
the position 0°.
With the MEWP stabilized, pressing the parking but-
ton P (Picture 8) on radio control, it is possible re-
turn the booms.
17. Proceed to the automatic destabilization
through the lever 11 (Picture 8) on radio con-
trol station or to manual destabilization by the
outriggers control station (Picture 13).
IT IS ESSENTIAL TO CARRY OUT THE
DESTABILIZATION BY OPERATING ON
ALL FOUR LEVERS SIMULTANEOUSLY.
18. Once the tracks are on the ground, drive the
MEWP in the storage area through the travel
controls (par. 4.3.3).
If full lithium version (*optional), at the
end of the work, always remember to
charge batteries.
4.4.7 "Home" function
The following procedure should be car-
ried out with the most caution and wear-
ing all personal protective equipment.
This function is very useful at the end of works to
set the platform in transport configuration.
When the appropriate button (dead man) "Home"
(12 Picture 8), present on the radio control station,
