CMC S19HD - Specifications; Technical Sheet

MAN.234 Rev.6 ENG - Use and maintenance manual S19HD page 9 of 126
2 Specifications
2.1 Technical sheet 
PERFORMANCE
Max. working height
18,70 m
61.35 ft
Max. work outreach
(with 200/220 kg)
8,60 m
28.22 ft
TUV
Max. work outreach
with rotating basket*
(80 kg)
11,90 m
39.04 ft
Max. work outreach
with fixed basket
(80 kg)
11,60 m
38.06 ft
CE
Max. work outreach
with rotating basket*
(80 kg)
11,40 m
37.40 ft
Max. work outreach
with fixed basket
(80 kg)
11,10 m
36.42 ft
TUV
Max. load
on the basket
220 kg
485 lb
CE
200 kg
441 lb
Turret rotation
+/-355° (tot. 710°)
Basket rotation (*optional)
+90°/-87°
Max. slope to stabilize
27°/51%
Max. ramp attack slope
with jib lifted/engine side
28°-31°/53%-60%
Max. slope to travel
longitudinally/transversally
17°-10°/31%-18%
Travel speed
0,24 - 1,8
km/h
0.15 - 1,2
mph
DIMENSIONS
Basket height
1,10 m
3.61 ft
Basket width
0,60/0,70 m
1.97/2.30 ft
Basket length
0,80/1,40 m
2.62/4.59 ft
Total length with
rotating basket*
4,75 m
15.58 ft
Height in transport
configuration
1,98 m
6.50 ft
Total width
(without basket)
0,90 m
2.95 ft
Clearance from
the ground in
transport config.
0,18 m
0.59 ft
Max. height to
stabilize on an
obstacle (with
tracks lifted)
1,10 m
3.61 ft
