MAN.234 Rev.6 ENG - Use and maintenance manual S19HD page 10 of 126
Tracks (l x w x h)
1,75x0,25x0,36
m
5.74x0.82x1.18
ft
Tracks widening
(*optional)
0,90/1,30 m
2.95/4.27 ft
Max. longitudinal
stabilization
4,05 m
13.29 ft
Max. cross
stabilization
3,50 m
11.48 ft
Intermediate cross
stabilization
3,07 m
10.07 ft
Min. longitudinal
stabilization
3,50 m
11.48 ft
Min. cross
stabilization
2,66 m
8.73 ft
Outriggers plate Ø
0,18 m
0.59 ft
WEIGHT AND PRESSURES
Total weight (standard
equipment)
2670 kg
5885 lb
(R) Max. pressure
on the foot
6,6 kg/cm²
(64,72 N/cm²)
93.87 lb/in
2
(S) Max. pressure on
tracks
0,17 kg/cm²
(1,67 N/cm²)
2.42 lb/in
2
(T) Max. pressure in
travel
400 kg/m²
(3,92 KN/m²)
81.93 lb/ft
2
(U) Max. pressure in
work (wide area)
228 kg/m²
(2,24 KN/m²)
46.70 lb/ft
2
(V) Max. pressure in
work (narrow area)
242 kg/m²
(2,38 KN/m²)
49.57 lb/ft
2
Max. pressure in work
(mixed area)
236 kg/m²
(2,31 KN/m²)
48,34 lb/ft2
POWERS
Standard
hydraulic feed
1) Honda iGX390 petrol, 8.7 kW (11.7
HP), 3600 rpm
*Optional feeds
2) Yanmar L100W diesel, 6.8 kW (9.3
HP), 3600 rpm
3) Kubota Z602-E4B diesel, 10.8 kW
(14.5 HP), 3200 rpm
4) Electric engine 110/120/230 V
5) Motor G0901306, 9 kW, 48 V,
with lithium batteries 160 Ah
6) Hybrid version
Fuel tank
capacity
6,1/15 l
