MAN.234 Rev.6 ENG - Use and maintenance manual S19HD page 11 of 126
Max allowed speeds according to USA/EU standards
Max allowed lifting and de-
scending speed of the MEWP
0,4 m/s (1.31 ft/s)
Max allowed boom extension and
withdrawal speed
0,4 m/s (1.31 ft/s)
Max allowed rotation speed
0,7 m/s (2.3 ft/s)
Max allowed manual force in the
basket with 1 operator
400 N
Tightening
torque
Bolts of the bearing
M16 cl 10.9
28 daNm
