CMC S28 User Manual

MAN.243 Rev.5 ENG - Use and maintenance manual S28 page 114 of 138
11 Stability and
overload tests
During the commissioning of the machine, in
the final test, we carried out the following
stability and overload tests to verify S25
structural strength.
These tests shall be carried out only on the first
test of the machine. You shall not repeat tests
with the same loads.
NOTES.
NL: nominal load.
TL: test load.
Stability tests
Test
n°
Load
(Kg)
Booms position
Side
Outco
me
Outre
ach
(m)
Boom 2
Boom 1
1
230
(NL)
+
260
(TL)
10,50
Horizon
tal
Complet
ely
retracted
and lifted
Lateral
(at
1.5°)
OK
2
80
(NL)
+
167
(TL)
13,00
Horizon
tal
Complet
ely
retracted
and lifted
Lateral
(at
1.5°)
OK
Overload tests
Test
n°
Load
(Kg)
Booms position
Side
Outco
me
Outre
ach
(m)
Boom 2
Boom 1
1
230
(NL)
+
58
(TL)
10,50
Horizon
tal
Complet
ely
retracted
and lifted
Lateral
OK
2
80
(NL)
+
20
(TL)
13,00
Horizon
tal
Complet
ely
retracted
and lifted
Lateral
OK
