MAN.243 Rev.5 ENG - Use and maintenance manual S28 page 62 of 138
following maneuvers must be carried out up to the limit
switches in the chronological order indicated below:
o booms return up to 0°;
o turret rotation in the direction of origin up to 0°;
o descent of first boom group up to 0°;
o descent of all booms up to support.
CAUTION! IF YOU MEET OBSTACLES DURING
THE AUTOMATIC CLOSURE OF THE
MACHINE, IMMEDIATELY RELEASE THE
BUTTON AND PROCEED WITH THE MANUAL
MANOEUVRES.
4.4.8 Acoustic warnings
16. During the use of the MEWP, it is possible to
hear the following acoustic warnings,
corresponding to the following signals:
 SOUND 
Corresponding to:
Continuous acoustic
signal (intermittent in pre-
alarm): when exceeding
the maximum load
allowed.
Load limiter light
activated on basket
console and on radio
control.
Continuous acoustic
signal (intermittent in pre-
alarm): when exceeding
the maximum travel
inclination allowed.
Maximum travel
inclination light activated
on basket console and
on radio control.
Table 2: acoustic signals.
4.5 Lithium battery pack recharge
(*optional)
For full lithium version (*optional), in order to recharge
the battery pack, it will be necessary to stall the machine.
Then operate according to the following procedure:
1. switch off the electric engine;
2. couple the 110/120/230 V plug (power line) to the
connector on the machine and press the
appropriate button of the magnetothermic switch;
3. now the batteries will be in charge and the charge
progress can be evaluated through the leds on
chassis box or on radio control station.
