MAN.243 Rev.5 ENG - Use and maintenance manual S28 page 61 of 138
4.4.6 Setting the MEWP in the transport
configuration
13. In order to set the MEWP in the transport
configuration, first center the turret, return on
the ground the MEWP aerial part, withdrawing
the telescopic boom groups, and laying the
booms on their supports, using the platform
control (exercise) station (par. 3.2.1).
WARNING! CENTER THE TURRET BEFORE
LOWERING BOOMS.
14. Unfasten safety belts and get off the basket
using the steps below.
If you want to destabilize the machine:
o In case of manual destabilization, keep the dead
man button pressed and use the levers of the
main inlet group (par. 4.4.2.1).
o If you want to automatically destabilize the
machine, rotate the selector near the ignition key
on 1 and use the properly buttons on the radio
control or on the basket console (par. 4.4.2.2-
4.4.2.3).
15. At the end, it is possible to restart the MEWP
to take it back to the parking place.
IT IS ESSENTIAL TO CARRY OUT THE
DESTABILIZATION BY OPERATING ON ALL
FOUR LEVERS SIMULTANEOUSLY.
Keeping the parking button P (Picture 16) pressed,
together the J5 joystick which control the turret rotation,
you can activate the turret self-centering up to the
position 0°.
With the MEWP stabilized, pressing the parking button P
on radio control (Picture 16), it is possible return the two
boom groups.
If full lithium version (*optional), at the end of
the work, always remember to charge
batteries.
4.4.7 “Home” function
The following procedure should be carried out
with the most caution and wearing all
personal protective equipment.
When the appropriate button (dead man) "Home",
present both on the radio control and on the basket
control station (Picture 11 and 16), is held pressed, the
automatic closing of the aerial part is activated. The
