CMC S28 User Manual

MAN.243 Rev.5 ENG - Use and maintenance manual S28 page 9 of 138
2 Specifications
2.1 Technical sheet
PERFORMANCE
Max. work height
27,90 m
91.54 ft
Min. work height
-6,70 m
21.98 ft
Max. work outreach
(with 80 kg)
14,00 m
45.93 ft
Max. work outreach
(with 140 kg)
13,00 m
42.65 ft
Max. work outreach
(with 230 kg)
11,50 m
37.73 ft
Max. load on the basket
230 kg
507 lb
Jib movement
90°
Turret rotation
+/-200° (tot. 400°
continuous)
Basket rotation
+/-90°
Max. slope to stabilize
32°/62%
Max. slope approach angle with
tracks widened (front/rear)
13°-17°/23%-31%
Max. slope approach angle with
tracks narrowed (front/rear)
7°-10°/12%-18%
Max. slope to travel
(longitudinally/transversally)
19°-8°/34%-14%
Max. chassis inclination
1°
Travel speed
0,5 - 2,4
km/h
0.3 - 1.5
mph
BASKETS
Basket height
1,10 m
3.61 ft
Standard basket:
Two-men aluminum
m
1,70x0,70
ft
5.58x2.30
*Optional baskets:
Two-men aluminum
One-man aluminum
Two-men fiberglass
One-man fiberglass
m
1,20x0,70
0,80x0,60
1,40/1,20x0,60
0,80x0x60
ft
3.94x2.30
2.62x1.97
4.59/3.94x1.97
2.62x1.97
DIMENSIONS
Total length with
basket
6,80 m
22.31 ft
Length with basket
support rotated
(without basket)
6,10 m
20.01 ft
Height in transport
configuration
(with tracks
narrowed/widened)
1,99/2,19 m
6.54/7.19 ft
Total width
(without basket)
0,90 m
2.95 ft

CMC S28 Specifications

General

Brand	CMC
Model	S28
Category	Boom Lifts
Language	English
