CMC S28 User Manual

MAN.243 Rev.5 ENG - Use and maintenance manual S28 page 10 of 138
Clearance from the
ground in transport
configuration
(with tracks
narrowed/widened)
0,17/0,32 m
0.56/1.05 ft
Clearance under tracks
with machine stabilized
1,05 m
3.44 ft
Tracks (L x w)
1,75 x 0,25 m
5.74 x 0.82 ft
Tracks widening
0,89/1,40 m
2.92/4.59 ft
Tracks lifting
0,18/0,33 m
0.59/1.08 ft
STABILIZATION AREA
Outrigger spread length in
wide stabilization area
6,67 m
21.88 ft
Outrigger spread width in
wide stabilization area
4,43 m
14.53 ft
Outrigger spread length in
narrow stabilization area
5,22 m
17.13 ft
Outrigger spread width in
narrow stabilization area
2,67 m
8.76 ft
Outrigger spread width in
mixed stabilization area
3,63 m
11.91 ft
Outriggers foot diameter Ø
0,24 m
0.79 ft
WEIGHT AND PRESSURES
Total weight
(standard equipment)
4150 kg
9150 lb
(R) Max. pressure on the
foot
5,84 kg/cm²
(57,23 N/cm²)
83.06 lb/in
2
(S) Max. pressure on the
track
0,28 kg/cm²
(2,72 N/cm²)
3.98 lb/in
2
(T) Max. pressure in
travel
772 kg/m²
(7,57 KN/m²)
158 lb/ft
2
(U) Max. pressure in work
(wide outrigger setup)
146 kg/m²
(1,43 KN/m²)
29.90 lb/ft
2
(V) Max. pressure in work
(narrow outrigger setup)
213 kg/m²
(2,09 KN/m²)
43.63 lb/ft
2
(Z) Max. pressure in work
(one side wide, one side
narrow)
172 kg/m²
(1,69 KN/m²)
35.23 lb/ft
2
