4.2 View of the Dual Unit Installation
The following figure illustrates the Quad-band DIGI-mini assembly.
The following figure illustrates the Triple/Quad-band DIGI-mini assembly.
Note the following:
• The Tri/Quad-band assembly supports
two RF combiners , mounted on each side bracket.
• The front panel LED interfaces are interconnected and covered with a common tab.
NOTE: Illustration below shows a bottom view of the mounted Quad-band assembly (connectors face
down when the assembly is wall mounted).
Figure 4-1: Cascaded DIGImini Tri/Quad-band
4.3 Required Tools and Materials
The following is required in order to install the Repeater:
• Standard professional tool box
• A computer (i.e. laptop for running the setup) – refer to the single/dual band user manual for
setup and commissioning procedure.
DIGImini Unit
Combiner-
one on
each side
Power Supply
–
one on each
side
Cascading
Bracket –
on
each side
DIGImini Unit
Common
indicators
Wall bracket
Spacer between
Combiner and bracket
