4.4.2 Middle layer Items
NOTE: References to Type I and Type II DIGImini models are explained in the following sections
when the relevant instructions are given.
Figure 4-4. Quad-Band Kit -Middle Layer items
4.4.3 Bottom Layer Items
Figure 4-5. Quad-Band Kit-Bottom Layer Items
Flat Cable +
Combiner Spacers
X1 Quad-
band
plate for Type I +
Type II units
Labels for
Type 2 only
and Type1 +
Type 2
x3 Quad-band plate
for two
Type I units
RF Combiner
RF Combiner
x1 Quad-band plate
for Type II only
2 x Expansion, Side
Brackets
