DIGIMINI EMEA/APAC/AUSTRALIA REPEATERS
PRODUCT DESCRIPTION AND USER’S MANUAL
Cobham Wireless – Coverage Date: 11-Oct-15 www.cobham.com/wireless
Document number: 00030UM Rev. 5.0
Page |B- 1
Appendix A: Specifications
700 MHz Frequency band (Lower) Uplink Downlink
Operating frequency range 703-738MHz 758-793MHz
Output power at antenna port (composite) 20dBm 20dBm
Pass band maximum gain 73dB 73dB
Gain attenuation range 0-25dBm (in 1dB steps) 0-25dBm (in 1dB steps)
Pass band ripple ± 2.5dB ± 2.5dB
Noise figure @ max gain 6dB 6dB
Propagation delay 6 μsec 6 μsec
Number of filters per band* Up to 8 Up to 8
700 MHz Frequency band (Upper) Uplink Downlink
Operating frequency range 713-748MHz 768-803MHz
Output power at antenna port (composite) 20dBm 20dBm
Pass band maximum gain 73dB 73dB
Gain attenuation range 0-25dBm (in 1dB steps) 0-25dBm (in 1dB steps)
Pass band ripple ± 2.5dB ± 2.5dB
Noise figure @ max gain 6dB 6dB
Propagation delay 6 μsec 6 μsec
Number of filters per band* Up to 8 Up to 8
850 MHz Frequency band (**) Uplink Downlink
Operating frequency range 824-849MHz 869-894MHz
Output power at antenna port (composite) 20dBm 20dBm
Pass band maximum gain 73dB 73dB
Gain attenuation range 0-25dBm (in 1dB steps) 0-25dBm (in 1dB steps)
Pass band ripple ± 2.5dB ± 2.5dB
Noise figure @ max gain 6dB 6dB
Propagation delay 6 μsec 6 μsec
Number of filters per band* Up to 8 Up to 8
900 MHz Frequency band(**) Uplink Downlink
Operating frequency range 880-915MHz 925-960MHz
Output power at antenna port (composite) 20dBm 20dBm
Pass band maximum gain 73dB 73dB
Gain attenuation range 0-25dBm (in 1dB steps) 0-25dBm (in 1dB steps)
Pass band ripple ± 2.5dB ± 2.5dB
Noise figure @ max gain 6dB 6dB
Propagation delay 6 μsec 6 μsec
Number of filters per band* Up to 8 Up to 8
Continued on the next page….
