COBHAM DIGImini Series - Page 66

DIGIMINI EMEA/APAC/AUSTRALIA REPEATERS
PRODUCT DESCRIPTION AND USER’S MANUAL
www.cobham.com/wireless
Page | A-2
Cobham Wireless – Coverage
Document number: 00030UMCD
Date: 11-Oct-15
Rev. 5.0
1800 MHz Frequency band Uplink Downlink
Operating frequency range 1710-1785MHz 1805-1880MHz
Output power at antenna port (composite) 20dBm 20dBm
Pass band maximum gain 73dB 73dB
Gain attenuation range 0-25dBm (in 1dB steps) 0-25dBm (in 1dB steps)
Pass band ripple ± 2.5dB ± 2.5dB
Noise figure @ max gain 6dB 6dB
Propagation delay 6 μsec 6 μsec
Number of filters per band* Up to 8 Up to 8
2100 MHz Frequency band Uplink Downlink
Operating frequency range 1920-1980MHz 2110-2170MHz
Output power at antenna port (composite) 20dBm 20dBm
Pass band maximum gain 73dB 73dB
Gain attenuation range 0-25dBm (in 1dB steps) 0-25dBm (in 1dB steps)
Pass band ripple ± 2.5dB ± 2.5dB
Noise figure @ max gain 6dB 6dB
Propagation delay 6 μsec 6 μsec
Number of filters per band* Up to 8 Up to 8
2600 MHz Frequency band Uplink Downlink
Operating frequency range 2500-2570MHz 2620-2690MHz
Output power at antenna port (composite) (***) 20dBm 20dBm
Pass band maximum gain 73dB 73dB
Gain attenuation range 0-25dBm (in 1dB steps) 0-25dBm (in 1dB steps)
Pass band ripple ± 2.5dB ± 2.5dB
Noise figure @ max gain 6dB 6dB
Propagation delay 6 μsec 6 μsec
Number of filters per band* Up to 8 Up to 8
General RF specification
Max. RF input power +10 dBm
Electrical specification
Power supply / Power consumption
110/240 VAC / <70 Watt for dual band
Environmental specification
Operating temperature range -10 to 50°C
Humidity 85%, ETS 300 019-1-3 Class 3.1
Mechanical specification
Dimension / Weight 299 x 305 x 77 mm (b x h x d) / 4 kg for dual band
Installation wall mount
Ingress Protection IP41
Complies with
ETSI EN 301 502, (ETSI EN 300 609-4/GSM 11.26), ETSI
EN 301 489 - 8, ETSI EN 301 489 - 23, ETSI TS 125 106,
3GPP TS 25 106, 3GPP TS 36-106
* Supports every BW option 200 kHz-25MHz by setting the start-stop frequency. Total number of filters is 8 and up to 100MHz
accumulated bandwidth in each dual band unit (1 filter resource provides up to 11 MHz bandwidth, 2 filter resources up to
25MHz bandwidth)
** Combining 850MHz and 900MHz bands together may require using external filters.
*** To pass the ACMA requirement on 2600MHz composite power should be reduced by 3dB (17dBm)
