Serial setup for iDirect iNFINITI & Evolution
98-145510-E Appendix C: VSAT modem settings C-21
C.3.2 Console port settings
The iDirect modem must be configured to use the following console port settings:
• Baud rate: 4800 or 9600
• Data bits: 8
•Parity: None
•Stop bit: 1
Passwords
The ACU will log in to the modem using root and user passwords. The default passwords
are:
• Root: P@55w0rd!
•User: iDirect
Supported commands
After login to the modem the ACU will issue commands to the modem every second. The
following commands are supported by the ACU:
•rx snr
•options show FREQ_TRANS
•rx freq
•tx freq
2
• latlong <lat> <long>
The signal strength command: rx snr is issued every 2 seconds. The rest of the commands
are issued one by one every 2 seconds between each signal strength command. Meaning
each of the other commands is issued every 8 seconds.
The signal strength in the ACU display and web interface is shown as dB., e.g: 8.5 dB. The
minimum value for Internet connection is around 2-3 dB.
2. Not supported from version 15 (iDirect). Causes a TX frequency warning on the
EXPLORER VSAT system
