COBHAM SAILOR 6282 - System LEDs and Application Management

Maintenance
98-135323-H Chapter 3: Service & maintenance 53
System LEDs
App installation and system settings
The AIS app is installed in the SAILOR 6004 Control Panel during installation of
the SAILOR 6280/6281 AIS System.
Figure 43: LEDs on the SAILOR 6282 AIS Transponder
LED Colour Description
Power Green Power on.
Rx Yellow Rx mode. Lights up when a message is received. Off when
no activity.
Tx Red Tx mode. Lights up when a message is transmitted. Off
when no activity.
