98-175666-C Appendix F: Event messages F-6
List of events
08534-0 ADM WARNING BDU
communication
The communication link between BDU and
antenna is not working.
08537-0 ADM INFO GNSS
communication
Lost connection to the GNSS device.
08538-0 ADM INFO GNSS data range Received information from the GNSS device
which is out of range.
08539-0 ADM WARNING GNSS device
warning
Local GNSS device warning.
0853A-0 ADM WARNING GNSS device error Local GNSS device error.
08541-0 ADM WARNING BUC voltage low The voltage for the BUC is too low, probably
caused by a malfunctioning VIM or BUC. (!T,!G)
08542-0 ADM WARNING BUC voltage high The voltage for the BUC is too high probably
caused by a malfunctioning VIM. (!T,!G)
08543-0 ADM WARNING LNB voltage low The voltage for the LNB is too low probably
caused by a malfunctioning VIM or LNB.
08544-0 ADM WARNING LNB voltage high The voltage for the LNB is too high probably
caused by a malfunctioning VIM.
08546-0 ADM WARNING Antenna
temperature
The temperature of the antenna is too high.
Check if the fan is working. (!T,!G)
0854A-0 ADM INFO Xel encoder slip A slip of the cross-elevation encoder has been
detected. If this event is not resolved by itself
after some time, check the belt and encoder of
the cross-elevation axis.
0854D-0 ADM WARNING GNSS position No position available from the GNSS device or
position too old.
0854E-0 ADM INFO GNSS velocity No velocity available from the GNSS device.
0854F-0 ADM WARNING Heading data Heading information is missing in the antenna.
0855E-0 ADM WARNING Low elevation The antenna is not allowed to transmit because
the elevation is too low. (!T)
0855F-0 ADM WARNING Heading range Heading data range error. External heading
unit supplies unreliable data.
08562-0 ADM WARNING High elevation The antenna cannot perform acquisition in
gyro-free mode because the elevation is too
high.
ID Module Type Description Explanation
Table F-1: Event messages (Continued)
