COBHAM SAILOR XTR GX-R2 User Manual

98-175666-C Appendix F: Event messages F-8
List of events
08A03-0 ADM WARNING GX Core Module
power
The Power Good signal from the Core Module is
low. The issue can either be: - Internal Core
Module or internal cable failure - Temperature
of Core Module is too high and it has been
turned off (*) - GMU has been manually
switched off on the front panel (*) (*) = Only on
systems with GMU. (!V,!T)
08A04-0 ADM WARNING iDirect modem The BDU detected a warning/error in the iDirect
modem. Log into the modem for more
information. Info: 0x00000001: Temperature
error 0x00000002: Test error 0x00000004:
Fan error (!V,!T)
08A05-0 ADM WARNING GX Core Module
heating
The GX core module heater is active. It will
automatically be cleared when the core module
reaches the operational temperature level.
(!V,!T)
08B00-0 ADM INFO IoT med priority
msg rate exceeded.
The message rate limit has been reached for the
medium priority queue. The iothub client will
pause transmission of medium priority
messages for a short while.
08B01-0 ADM INFO IoT low priority msg
rate exceeded.
The message rate limit has been reached for the
low priority queue. The iothub client will pause
transmission of low priority messages for a
short while.
08B02-0 ADM INFO Iothub disabled The iothub client has been disabled.
09000-0 KDM ERROR KDM 3V3 supply Internal 3V3 voltage supply error in the KDM.
09001-0 KDM ERROR KDM 12V supply Internal 12V voltage supply error in the KDM.
09002-0 KDM ERROR KDM display Display hardware error in the KDM.
09010-0 KDM ERROR KDM link/SW
version
Link to the KDM module could not be
established. Either the KDM board is
malfunctioning, or - if the system software has
just been updated - the software is too old and
is not compatible with the KDM hardware.
0A080-0 Antenn
a
ERROR EBUS loop
interrupted
EBUS communication error, loop interrupted.
0A081-0 Antenn
a
ERROR ISCM error Communication error with ISCM. Info:
0x00000001: Key line signal
0A100-0 Antenn
a
ERROR ISCM Gyro
communication
Internal communication error on ISCM.
ID Module Type Description Explanation
Table F-1: Event messages (Continued)
