Preparing the 2110 SSB Transceiver for use
2110 SSB Transceiver Getting Started Guide 19
Connecting a battery to the transceiver
The battery is connected to the bottom of the transceiver. It is
held in place by clips with locking key latches (see Figure 2).
Figure 2: Transceiver with battery pack connected
NOTE
The battery connector on the base of the
transceiver is on the same side of the transceiver
as the antenna connectors on the front panel.
key
clip
transceiver
battery pack
