The front panel
2110 SSB Transceiver Getting Started Guide 31
The handset
The 2110 SSB Transceiver supports standard audio
accessories using H-229 type connectors. The handset is a
standard issue, lightweight, tactical H-250/U type, with built-
in earphone, noise-cancelling microphone, and PTT button. It
is connected to the 6-way connector on the front panel of the
transceiver.
Figure 6: The handset
earphone
microphone
PTT
