2110 SSB Transceiver Getting Started Guide 57
CODAN
Appendix D—Transceiver
specifications
Table 6: Specifications
Item Specification
Frequency range Transmit: 1.6 to 30 MHz
Receive: 250 kHz to 30 MHz
Channel capacity 400 channels
Operating modes Single sideband (J3E) USB and LSB or switched USB/LSB,
AM H3E (optional)
Sensitivity Frequency:
0.25 to 30 MHz
RF amp off:
0.28 µV PD, –118 dBm
Frequency:
1.6 to 30 MHz
RF amp on:
0.14 µV PD, –124 dBm
For 10 dB SINAD with greater than 50 mW audio output
Power output 25 W PEP ±0.5 dB (high power)
5 W PEP ±0.5 dB (low power)
Antenna tuning
times
First time tuning 2.5 s typical
Memory tuning 50 ms typical
Approximate
battery life
13 Ah NiMh: 50 h
8Ah NiMh: 30h
7 Ah SLA: 15 h
Environment Ambient temperature: –30 to 60°C
Relative humidity: 95% non-condensing
Derate upper ambient temperature by 1°C per 330 m (360 yd)
above sea level
