X-2 Technical Service Manual 1-1
Publication No: 15-02047
1 Introduction
1.1 Purpose
The purpose of this manual is to provide a technical description, details and
drawings about the X-2 transceiver for the technician to understand the:
• function
• technical operation
• fault diagnosis
• dismantling and assembly
• setup and adjustment procedures
1.2 How this manual is organised
The X-2 Technical Service Manual is organised as follows:
Chapter 1
An overview of the features of the X-2 transceiver
including specifications.
Chapter 2
A brief description of the X-2 transceiver with a general
description of the major circuit functions for the control,
reception and transmission of signals.
Chapter 3
Operating instructions for the X-2 transceiver.
Chapter 4
A more detailed technical description of the operation
and circuit function of the X-2 transceiver. Read this
with the associated technical drawings found in the
appendices.
Chapter 5
Maintenance, general cautions and warnings, fault
diagnosis procedures associated with the maintenance of
the X-2 transceiver.
Chapter 6
Programming procedures for channel additions.
Chapter 7
Adjustments, checks and alignments to the X-2
Transceiver detailing required test equipment.
Chapter 8
Comprises four appendices. Connector tables, parts lists,
engineering drawings and glossaries.
