Code 2600 User Manual

C007964_01_CR2600_User_Manual
2.0 - Baery Installaon and Removal
1.0 - Unpacking
Remove the CR2600 from its packing and inspect it for damage. If the reader was damaged during shipping, please call Code at
(801) 495-2200.
1. Plug the barrel side of the USB charge cable or power supply into power jack of the charger.
Place the baery into the reader as shown below. Once in place, the baery will snap and lock to indicate proper installaon. For baery
removal, slide the latch, to unlock and release the baery.
3.0 - Charging the CR2600
1
Based on the kit purchased, a combinaon of the following components will be included with the CR2600:
Charging Staon with
Embedded CodeXML Modem
Charging Staon
USB Cable
Power SupplyCodeXML® M3 Modem
Baery
Latch

Code 2600 Specifications

General

Operating Temperature	0°C to 50°C (32°F to 122°F)
Voltage	5 VDC ± 10%
Resolution	4 mil
Interface	USB, RS232, Keyboard Wedge
Supported Barcodes	Code 39, Code 128, UPC/EAN, Interleaved 2 of 5, Codabar, MSI
Humidity	5% to 95% (non-condensing)
