Page 35
800 Series
SECTION 6: EXPLODED VIEWS
ITEM NO. DESCRIPTION
1 Mainplate and Coil
2 Operating Lever Spring
3 Operating Lever
4 Retaining Ring
5 Gate Lever Pivot Screw
6 Gate and Coil Assembly
7 Gate Board
8 Keypad
9 Gate Cover
10 Label
11 Front Cover
12 Intermediate Cover
13 Label, Mirror .575
14 Debounce, Validation
15 Debounce, Sorting
16 Hand Loading Door
17 Hand Loading Door Spring
18 Accept/Reject Door
19 Sort Door
20 Cashbox Door
21 Pivot Diverter Pin
22 Short Diverter Pin
23 Coin Stop
24 Plunger and Yoke Assembly
25 Tube “C” and Plunger Assembly
26 Copper Plated Spring
27 Solenoid Coil Assembly
28 “C” Frame Solenoid
29 Tube “B” and Plunger Assembly
30 Spring Retention Plug
31 Self Locking Hex Nut
32 Logic Board
33 Rear Cover
34 Acceptor Label
35 Debounce Plate
36 Patent Label
37 Foam (not shown)
38 Foam (not shown)
39 Screw, Pan Head #4x5/16
40 Global Decal
41 Anti-Stringing Lever
42 Screw, Flat Head #4x5/16
43 Acceptor Gasket
44 Insert, Mainplate (selective models only)
45 Screw, Flat Head #2x3/16
(selective models only)
46 Gate/Board assembly (for service only)
800 Series Acceptor Assembly
