Coinco GLOBAL2 - Page 36

Page 36 800 Series
DEX HARNESS
(CONNECTOR)
“G” (MDB) HARNESS
(CONNECTOR)
DISPLAY
(CONNECTOR)
PROTOCOL “A” HARNESS
WITH STRAIN RELIEF
(CONNECTOR)
DATA LINK HARNESS
PROTOCOL “A”
WITH STRAIN RELIEF
(CONNECTOR)
“G” (MDB) HARNESS
PROTOCOL “A”
HARNESS
“A” COM
DEX/MIS
HARNESS
PROTOCOL“A” CONFIGURATION
SECTION 6: EXPLODED VIEWS
800 Series Harness and Logic Board Configuration
“G” (MDB) HARNESS
407544
SMALL PLUG
LARGE PLUG
(2 REQ’D)
“G” (CONNECTOR)
407499
“G” (MDB) CONFIGURATION
