Coinco GLOBAL2 - Page 37

Page 37
800 Series
“F/S” CONFIGURATION
BILL VALIDATOR
(CONNECTOR)
DEX/MIS HARNESS
(CONNECTOR)
“G” (MDB)
HARNESS
(CONNECTOR)
PRIMARY TRANSFORMER (CONNECTOR)
SINGLE/FOUR-PRICE HARNESS
(CONNECTOR)
BILL VALIDATOR (CONNECTOR)
DISPLAY (CONNECTOR)
SECONDARY TRANSFORMER
(CONNECTOR)
DEX/MIS
HARNESS
“G” (MDB) HARNESS
407544
SINGLE/FOUR-PRICE HARNESS
407864
LARGE PLUG
800 Series Harness and Logic Board Configuration
PROTOCOL“A” WITH MDB MASTER CONFIGURATION
