COMAC ARJ21-700 - Aircraft Protection Equipment - Support Equipment Installation

ARJ21-SVV19-13120-00
RampServicingOperation
Instruction
Aircraftprotectionequipment-SupportequipmentInstallation
1.CommonInformation
A.Thissectionprovidesinformationtoinstallthefollowingprotectiveequipmentontheaircraft.
2.PreliminaryRequirements
WorkZones
ZoneLocation
100Lowerhalfofthefuselage:allradomeofSTA7-STA37,and
STA37-STA897.926lowerhalfofthebulkhead.(Thelower
halfistheareabelowthefuselagereferenceplane)
200Upperhalfofthefuselage:STA37-STA897.926bulkhead.
(Theupperhalfistheareaabovethefuselagereference
plane)
300FuselageTail
400PowerplantandPylon
500LeftWing
600RightWing
700LandingGearandLandingGearDoors
Equipments/Tools
NamePartnumberQTYRemarks
TorqueWrenchNoSpecicAsNec-
essary
Torquerange:100lbf.in-130lbf.in
（11.3N.m-14.7N.m）
WorkstandorClimbLadderNoSpecicAsNec-
essary
Null
NoseLandingGear
ProtectiveCover
632A110-A2
Null
MainLandingGearTire
Cover
632A100-A4
Null
EngineExhaustNozzle
BlankingCap(Left)
604C5818-0191
Null
(Opt:EngineExhaustNozzle
BlankingCap(Left))
(Opt:604C5818-
009)
(Opt:EngineExhaustNozzle
BlankingCap(Left))
(Opt:604C5818-
019)
(Opt:EngineExhaustNozzle
BlankingCap(Left))
(Opt:604C5818-
009)
ARJ21-A-13-12-07-01A-722A-A
Issue001,2023-01-29
Applicableto:ALL
Page1of11
