COMAC ARJ21-700 - Cargo Net - Technical Data

ARJ21-SVV19-13120-00
RampServicingOperation
Instruction
Cargonet-T echnicaldata
1.General
ThischapterprovidesthetechnicalrequirementsofcargonetsinARJ21aircraft.
2.Preparation
A.Zonal
NumberLocation
100Lowerfuselage:WholeradomeofSTA7-
STA37,andSTA37-STA897.926lowerhalfof
thebulkhead.(Thezoneoflowerfuselageis
theareaunderthefuselagereferenceplane)
200Upperfuselage:STA37-STA897.926
bulkhead.(Theupperhalfistheareaabove
thefuselagereferenceplane)
3.MainProcedure
1)Thefunctionofcargonets:
•Thenetsareusedtodividethecargo,andtopreventtheloadofthewholecargofromactingon
thecargostructureinacertaindirectionwhentheightattitudeofaircraftchangesduringtakeoff,
landingoright,resultingindamagetocagrostructure.
•Thenetscandividethegoodstobalancetheweight.
2)Themainnetsincargocompartmentareasfollows(Thespecicarrangementisshowningure
1andgure2).
•Fwdcargodoorbarrierisnearthedoor.
•Fwdcargofullnets'positionsareSD256,SD294,SD465andSD503.
•Fwdcargohalfnetsareatleftofthedoorbafeboards(Aftlookingforward).
•Aftcargofullnets'positionsareSD748.5,SD790andSD828.
ARJ21-A-13-12-10-01A-030A-A
Issue001,2023-01-29
Applicableto:ALL
Page1of6
