COMAC ARJ21-700 - ARJ21-A-13-12-00-01 A-030 A-A General Aircraft Dimensions - Technical Data

ARJ21-SVV19-13120-00
RampServicingOperation
Instruction
Generalaircraftdimensions-Technicaldata
1.General
Thissectioncontainsthedimensionsforthewing,horizontalstabilizer,verticalstabilizerandfuselage.
Italsocontainsareasforthewingandstabilizersurfaces.
2.Preparation
A.References
NumberNomenclature
SM110A0001ARJ21three-viewdrawing
B.Zonal
NumberLocation
100Lowerfuselage:WholeradomeofSTA7-
STA37,andSTA37-STA897.926lowerhalfof
thebulkhead.(TheZoneofLowerFuselageis
theareaundertheFuselageReferencePlane)
200Upperfuselage:STA37-STA897.926
bulkhead.(Theupperhalfistheareaabove
thefuselagereferenceplane)
300Empennage
400PowerplantandPylon
500Leftwing
600Rightwing
700LandingGearandLandingGearDoors
800Doors(SubjectedtothePressurizedLoads)
3.MainProcedure
A.DIMENSIONS
(1)Aircraft
(a)Height8.442m(332.36in)
NOTE:
Operationemptyweight(OEW)is24955kg.
(b)Length33.46m(1317.44in)
(c)Wingspan(includingwinglets)27.29m(1074.33in)
(2)Engine
(a)Enginenacelletogroundclearance-1.795(70.67)
NOTE:
Operationemptyweightis24955kg.
(b)Centerlineofpowerplantfwdmountplanetofuselagesymmetryplane-2.92m
(114.81in)
ARJ21-A-13-12-00-01A-030A-A
Issue001,2023-01-29
Applicableto:ALL
Page1of4
