ARJ21-SVV19-13120-00
RampServicingOperation
Instruction
(3)FUSELAGE
(a)Height:
1)Abovefuselagereferenceplane-2.34m(92.13in)
2)Belowfuselagereferenceplane-1.27m(50in)
(b)Fuselagetotallength-30.43m(1197.99in)
(c)Maximumfuselagewidth-3.34m(131.62in)
(4)HorizontalTail:
(a)Length10.51m(413.78in)
(b)Wingtipchord-1.19m(46.77in)
(5)LandingGear:
(a)Mainwheelspan-4.68m(184.25in)
(b)Noselandinggearspan-2.30m(90.64in)
(c)Wheelbase-14.88m(585.75in)
(6)VerticalT ail:
(a)Rootchord-4.74m(186.50in)
(7)Wing:
(a)Rootchord-4.97m(195.47in)
(b)Wingtipchord-1.29m(50.91in)
B.Area
(1)HorizontalTailReferenceArea-23.22㎡(249.89ft²)
(2)VerticalTailReferenceArea-14.96㎡(161.03ft²)
(3)WingReferenceArea-79.86㎡(859.60ft²)
ARJ21-A-13-12-00-01A-030A-A
Issue001,2023-01-29
Page2of4
Applicableto:ALL
