Figure6Thearrangementofhalfnetsattachmentpoints(Sheet1of1)
6.3Attachmentttingsandconnectingbracketsofcargonetsandstructure
AttachmentttingsshouldmakeARJ21aircraftcargonetsadjustable.Normalttingsshouldbegen-
eralandinterchangeable.
6.4Thenumbersofcargonetsandconnectingbracketsareshownintable1.
Table1Table1Aircraftcargonetsequipmentlist
FORWARDCARGO
COMPARTMENT
AFTERCARGO
COMPARTMENT
fullcargonets(Type1)
includesttings
42
fullcargonets(Type2)
includesttings
1(SD828)
halfcargonetsincludesttings2
Mount3018
6.5Distributionofloadinaircraftcargocompartment
ThemaximumavailiblelineloadofFwdCargoCompartment(FCC)is428.6kg/m(24lb/in).Themax-
imumavailiblelineloadofAftCargoCompartment(ACC)is401.8kg/m(22.5lb/in).
Thedesignoverloadrequirementsofcargonetsarefollowing:
Longitudinal_Forward3g,Afterward1.5g
Lateral_Left1.5g,Right1.5g
ARJ21-A-13-12-10-01A-030A-A
Issue001,2023-01-29
