ARJ21-SVV19-13120-00
RampServicingOperation
Instruction
WASTE SERVICE PANEL
AFT CARGO COMPARTMENT
AFT BULKHEAD PANEL
WASTE SERVICE PANEL
LIGHT
[5] HANDLE OF RINSE WATER NIPPLE
[4] WASTE SERVICE ACCESS
PANEL SWITCH WAFER
[3] WASTE SERVICE ACCESS PANEL
[8] SERVICE PANEL SWITCH
[9] DRAIN BALL VALVE
LEVER
[1] WASTE TANK DRAIN BALL
VALVE
[2] WASTE SERVICE PANEL
[6] RINSE WATER
NIPPLE
ICN-ARJ21-A-121701-A-SVV19-00832-A-001-01
Figure1Wasteservicedoor(Sheet1of1)
ARJ21-A-13-12-24-01A-228A-A
Endofdatamodule
Issue001,2023-01-29
Applicableto:ALL
Page3of3
