COMAC ARJ21-700 - Page 28

ARJ21-SVV19-13120-00
RampServicingOperation
Instruction
Metric
(mm)
English
(in)
Metric
(mm)
English
(in)
Metric
(mm)
English
(in)
Metric
(mm)
English
(in)
Number
C.G.FWDLimitC.G.AFTLimitC.G.FWDLimitC.G.AFTLimit
A8530335.88475333.78520335.48466333.3
B4579180.34598181.04569179.94587180.6
C179670.7176769.6178670.3175869.2
D75129.674729.474229.273729.0
E8009315.37954313.17999314.97945312.8
F3236127.43191125.63227127.03182125.3
G226389.1230890.9225488.7229790.4
H224388.3229290.2223387.9228289.8
I226589.2225288.7225588.8224288.3
J104040.9106742.0103040.6105641.6
K107842.4106041.7106842.0105141.4
L4545178.94502177.24535178.54493176.9
M7895310.87826308.17884310.47818307.8
N133952.7130851.5132952.3129951.1
Table5GroundClearancesatJackedStatus
DimensionNo.
Metric
(mm)
Imperial
in
A9022355.2
B5052198.9
C226689.2
D120947.6
E8506334.9
F3706145.9
G2686105.8
H2666105.0
I2728107.4
J147758.1
K154460.8
L5027197.9
ARJ21-A-13-12-00-02A-030A-A
Issue001,2023-01-29
Page6of26
Applicableto:ALL
