COMAC ARJ21-700 - Page 45

ARJ21-SVV19-13120-00
RampServicingOperation
Instruction
MaximumTaxiWeight-ERMaximumTaxiWeight-STD Operating
Empty
Weight
FWDCGAFTCGFWDCGAFTCG
Out-
side
air
tem-
pera-
ture
Description
Met-
ric
(mm)
Eng-
lish
(in)
Met-
ric
(mm)
Eng-
lish
(in)
Met-
ric
(mm)
Eng-
lish
(in)
Met-
ric
(mm)
Eng-
lish
(in)
Met-
ric
(mm)
Eng-
lish
(in)
Slat3Inboard
(SL3IN)
191275.3183272.1181171.3184472.6183372.2
Slat3Outboard
(SL3OUT)
205280.8198178.0194576.6199478.5197177.6
Slat1Inboard
(SL1IN)
152860.2143656.5144156.7144556.9145457.2
Slat1Outboard
(SL1OUT)
173268.2164764.8164064.6165865.3165765.2
Slat2Inboard
(SL2IN)
173368.2164864.9164164.6165965.3165765.2
Slat2Outboard
(SL2OUT)
190074.8182271.7180170.9183472.2182271.7
Slat3Inboard
(SL3IN)
190074.8182271.7180270.9183472.2182371.8
-40℃
Slat3Outboard
(SL3OUT)
204080.3197177.6193676.2198478.1196177.2
E
D
C
A
0
B
F
I
K
0
G
I
J
H
N
L
M
PASSENGER ENTRY
DOOR(TYPE I )
EMERGENCY EXIT
DOOR(TYPE I )
ICN-ARJ21-A-192002-A-SVV19-10703-A-002-01
Figure1GroundClearances(Sheet1of1)
ARJ21-A-13-12-00-02A-030A-A
Issue001,2023-01-29
Applicableto:ALL
Page23of26
