AIR SERVICE VALVE
WATER SERVICE PANEL
WATER FILLING
NIPPLE
ACCESS PANEL SWITCH
WATER SYSTEM INTERFACE
CONTROLLER
ICN-ARJ21-A-192005-A-SVV19-10784-A-001-01
Figure2Potabledrinkingwatergroundservicepanel.(Sheet1of1)
4.Wastewaterinterface.
A.Wastewaterservicepanel.
(1)Wastewaterservicepanelislocatedinthemiddlefuselage,1.60mmeanheightfromground.
ARJ21-A-13-12-00-03A-030A-A
Issue001,2023-01-29
Page4of13
Applicableto:ALL
