ComAp IG-NT - Page 303

IGS-NT Combi, SW Version 3.0, ©ComAp – May 2013
IGS-NT-Combi-3.0 Reference Guide.PDF
303
position.
Analog input: LdCtrl:AnExI/E
Related FW
3.0
Description
This functional input is used for requesting the mains import value externally by
an analog input. The setpoint Load ctrl PtM must be set to ANEXT IM/EX position.
Analog input: PFCtrl:AnExBPF
Related FW
3.0
Description
This functional input is used for requesting the gen-set cos phi factor externally
by an analog input. The setpoint PF ctrl PtM must be set to ANEXT BASEPF
position.
The analog value is transformed to the requested cos phi factor following way:
ANALOG VALUE
COS PHI FACTOR
<60
0.6L
60 .. 100
0.6L .. 1.00
101 .. 120
0.99C .. 0.80C
Analog input: PFCtrl:AnExI/E
Related FW
3.0
Description
This functional input is used for requesting the mains cos phi factor externally by
an analog input. The setpoint PF ctrl PtM must be set to ANEXT PF-IM/EX
position.
The analog value is transformed to the requested cos phi factor following way:
ANALOG VALUE
COS PHI FACTOR
<60
0.6L
60 .. 100
0.6L .. 1.00
101 .. 120
0.99C .. 0.80C
Analog input: LdCtrl:I/E-Pm
Related FW
3.0
Description
This functional input is used for connecting of an external device, which measures
the active power imported from the mains. The device is connected to the
controller via an analog input (e.g. -20 .. 20mA). The setpoint I/E-Pm meas must
be set to the ANALOG INPUT position for this case.
Analog input: PFCtrl:I/E-Qm
Related FW
3.0
