ComAp IG-NT Reference Guide

IGS-NT Combi, SW Version 3.0, ©ComAp – May 2013
IGS-NT-Combi-3.0 Reference Guide.PDF
98
Group: ProcCtrlSingle
Setpoint: Base load
Group
Process Control
Range [units]
0 .. Nomin power [kW]
Related FW
3.0
Description
This setpoint is used for adjusting of the requested gen-set power in Baseload
mode, i.e. if the setpoint Load ctrl PtM is set to BASELOAD.
NOTE:
The actual setpoint units and range depend on setting of the Power format in
GenConfig.
NOTE:
If the this setpoint is adjusted to lower value than Min Power PtM the gen-set
power is limited the Min Power PtM setpoint.
Setpoint: Base PF
Group
Process Control
Range [units]
0.60 .. 1.20 [-]
Related FW
3.0
Description
This setpoint is used for adjusting of the requested gen-set power factor value if
the power factor control mode is set to BASEPF (setpoint PF ctrl PtM).
Values over 1.00 mean capacitive load character, i.e. setting 0.95 means 0.95L
and setting 1.05 means 0.95C.
Setpoint: Import load
Group
Process Control
Range [units]
-32000 .. 32000 [kW]
Related FW
3.0
Description
This setpoint is used for adjusting of the requested mains import if the gen-set
load control mode is set to IMP/EXP (Load ctrl PtM = IMP/EXP)
This setpoint is also used for adjusting of the maximum allowed export if export
limit function is active (Export limit = ENABLED).
NOTE:
Negative value of import is export, i.e. the power flows into the mains.
NOTE:
The actual setpoint units and range depend on setting of the Power format in
GenConfig.
Setpoint: Import PF
Group
Process Control
