ONLY but in addition to it all load shedding outputs are
closed when gen-set group goes to island operation.
For more information see the chapter Load shedding.
ALL THE TIME
Outputs are controlled by the load shedding function
regardless of breaker positions.
NOTE:
Learn more about load shedding in the separate chapter Load shedding.
Setpoint: Ld shed level
Group
Load shedding
Range [units]
Ld recon level .. 200 [%]
Related FW
3.0
Force value
possible
YES
Description
This setpoint is used to adjust the relative load level (in % of nominal power of
gen-set) for load shedding. When the relative load level exceeds this level for
more than Ld shed delay time the next load shedding output is closed.
NOTE:
Learn more about load shedding in the separate chapter Load shedding.
Setpoint: Ld shed delay
Group
Load shedding
Range [units]
0.0 .. 600.0 [s]
Related FW
3.0
Force value
possible
YES
Description
This setpoint is used to adjust time period the relative load level must be above
the Ld shed level limit to close the next load shedding output.
NOTE:
Learn more about load shedding in the separate chapter Load shedding.
Setpoint: Ld recon level
Group
Load shedding
Range [units]
0 .. Ld shed level [%]
Related FW
3.0
Force value
possible
YES
Description
This setpoint is used to adjust the relative load level (in % of nominal power of
