CAUTION!
All controllers cooperating together in Power management must have the same
minimal running power selected.
NOTE:
It is possible to use virtual peripheries for distribution of the binary signal from one
physical switch connected to one controller to all other controllers over the CAN
bus. See the principial diagram of such distribution in the description of the input
Load res 2.
Binary input: MinRun power 2
Related FW
3.0
Description
This input is used to activate the function Minimal running power #2, which is
adjusted by setpoint #MinRunPower 2.
NOTE:
The default value of minimal running power, which takes place while none of the
inputs MinRun power x, is 0kW.
NOTE:
If more then one binary input for MinRunPower is activated, the one with the
highest number is used (i.e. its corresponding value).
CAUTION!
All controllers cooperating together in Power management must have the same
minimal running power selected.
NOTE:
It is possible to use virtual peripheries for distribution of the binary signal from one
physical switch connected to one controller to all other controllers over the CAN
bus. See the principial diagram of such distribution in the description of the input
Load res 2.
Binary input: MinRun power 3
Related FW
3.0
Description
This input is used to activate the function Minimal running power #3, which is
adjusted by setpoint #MinRunPower 3.
NOTE:
The default value of minimal running power, which takes place while none of the
inputs MinRun power x, is 0kW.
NOTE:
If more then one binary input for MinRunPower is activated, the one with the
highest number is used (i.e. its corresponding value).
CAUTION!
All controllers cooperating together in Power management must have the same
minimal running power selected.
NOTE:
It is possible to use virtual peripheries for distribution of the binary signal from one
physical switch connected to one controller to all other controllers over the CAN
