Binary input: Load res 3
Related FW
3.0
Description
This input is used to activate the load reserve set #3 instead of the set #1, which
is active by default. The set #3 is adjusted by setpoints:
• #LoadResStrt 3 and #LoadResStop 3 if the power management is
switched to absolute (kW-based) mode
• #%LdResStrt 3 and #%LdResStop 3 if the power management is
switched to relative (%Pnom-based) mode.
CAUTION!
All controllers cooperating together in Power management must have the same
load reserve set selected.
NOTE:
It is possible to use virtual peripheries for distribution of the binary signal from one
physical switch connected to one controller to all other controllers over the CAN
bus. See example in the description of the input Load res 2.
Binary input: Load res 4
Related FW
3.0
Description
This input is used to activate the load reserve set #4 instead of the set #1, which
is active by default. The set #4 is adjusted by setpoints:
• #LoadResStrt 4 and #LoadResStop 4 if the power management is
switched to absolute (kW-based) mode
• #%LdResStrt 4 and #%LdResStop 4 if the power management is
switched to relative (%Pnom-based) mode.
CAUTION!
All controllers cooperating together in Power management must have the same
load reserve set selected.
NOTE:
It is possible to use virtual peripheries for distribution of the binary signal from one
physical switch connected to one controller to all other controllers over the CAN
bus. See example in the description of the input Load res 2.
Binary input: MinRun power 1
Related FW
3.0
Description
This input is used to activate the function Minimal running power #1, which is
adjusted by setpoint #MinRunPower 1.
NOTE:
The default value of minimal running power, which takes place while none of the
inputs MinRun power x, is 0kW.
NOTE:
If more then one binary input for MinRunPower is activated, the one with the
highest number is used (i.e. its corresponding value).
