ComAp IG-NTC GC - Page 115

IGS-NT-BC, SW Version 1.2.0, ©ComAp – January 2019
IGS-NT-BC-1.2.0 Reference Guide.PDF
115
Setpoint: #%LdResStrt 2
Group
Pwr Management
Range [units]
0 .. #%LdResStop 2 [%]
Related FW
3.0
Description
This setpoint is used to adjust the load reserve for start in relative mode. i.e. Pwr
mgmt mode = REL (%) if the reserve set #2 is active. Learn more about reserves
in the chapter Reserves, minimal running power.
The currently active reserve set is selected by binary inputs Load res 2, Load res
3 and Load res 4. If none of these inputs is active the set #1 is selected.
Setpoint: #%LdResStop 2
Group
Pwr Management
Range [units]
#%LdResStrt 2 .. 110 [%]
Related FW
3.0
Description
This setpoint is used to adjust the load reserve for stop in relative mode. i.e. Pwr
mgmt mode = REL (%) if the reserve set #2 is active. Learn more about reserves
in the chapter Reserves, minimal running power.
The currently active reserve set is selected by binary inputs Load res 2, Load res
3 and Load res 4. If none of these inputs is active the set #1 is selected.
NOTE:
The reserve for stop must be always adjusted higher than the reserve for start.
Setpoint: #%LdResStrt 3
Group
Pwr Management
Range [units]
0 .. %LdResStop 3 [%]
Related FW
3.0
Description
This setpoint is used to adjust the load reserve for start in relative mode. i.e. Pwr
mgmt mode = REL (%) if the reserve set #3 is active. Learn more about reserves
in the chapter Reserves, minimal running power.
The currently active reserve set is selected by binary inputs Load res 2, Load res
3 and Load res 4. If none of these inputs is active the set #1 is selected.
Setpoint: #%LdResStop 3
Group
Pwr Management
Range [units]
#%LdResStrt 3 .. 110 [%]
Related FW
3.0
Description
This setpoint is used to adjust the load reserve for stop in relative mode. i.e. Pwr
mgmt mode = REL (%) if the reserve set #3 is active. Learn more about reserves
